Basic Info.
Molding Technics
Gravity Casting
Application
Machinery Parts
Material
Stainless Steel
Surface Preparation
Sand Blast
Surface Roughness
Ra6.3
Machining Tolerance
+/-0.02mm
Standard
ASME
Certification
CE, RoHS, ISO 9001:2000, ISO 9001:2008
Product Name
OEM Casting Service
Technology
Investment Casting, Die Casting, Gravity Casting
Surface
Sand Blasting, Polishing, Elctropolishing
Casting Tolerance
CT4-CT6
Inspection
100% Visual Inspection
Lead Time
30 Days
Package
Cartons+Wooden Case/Pallet
Certificates
ISO9001:2015
MOQ
100 PCS
Transport Package
Bubble Bag+Cardboad Carton+Pallet
Specification
OEM
Trademark
Hongsheng
Origin
China
HS Code
8302410000
Production Capacity
100tons/Month
Product Description
OEM aluminum/stainless steel/alloy steel/brass sand die casting precision investment casting service
| R&D | Softward: Solidworks, CAD, Procast, UG Development cycle of samples: 25-35 days |
| Materials | Stainless steel: 304/304L, 316/316L, 410/416 etc Duplex stainless steel: 2250, 2507 Carbon steel, Alloy steel, Aluminum,zinc alloy, brass/bronze... |
| Technical Parameter | Part weight: 2g to 30kgs Max dimension : 600mm for diameter or length Min wall thickness : 1.5mm Casting roughness: Ra3.2-6.4 Machining roughness: Ra1.6 Tolerance of casting: CT6 Inner core: ceramic core, urea core, water soluble wax core. |
| Heat treatment | Normalzing, Tempering, Quenching, Annealing, Quenching & Tempering, Caburization, Solution treatment. |
| Surface treatment | Polishing, bead blasting, zinc plating, hot dip galvanized, nickel plating, passivation, Electro-polising, mirror polishing, Brush polishing, PE coating, Powder coating, etc |
| Inspection | Cleanliness inspection, X-Ray radiographic inspection, MIM inspection |
| Production capacity | More than 120 tons per month |
| Quality Certificates | ISO9001 ISO14001 |
Name: Glass Clamp
Material: Stainless Steel 304/ Stainless Steel 316
Process: Investment Casting
Finish: Brush Polish
Name: Spider Fitting
Material: Stainless Steel 304/ Stainless Steel 316
Process: Investment Casting
Finish: Polish
Process: Investment Casting
Finish: Polish
Name: Pipe Fitting
Material:Stainless Steel 304
Process: Precision Casting
Finish: Sandblasting
Process: Precision Casting
Finish: Sandblasting
Name: Bearing Housing
Material: Stainless Steel 316
Process: Investment Casting
Finish: Sandblasting
Process: Investment Casting
Finish: Sandblasting
Name: Machinery Parts
Material: Stainless Steel 304
Process: Precision Casting
Finish: Sandblasting
Process: Precision Casting
Finish: Sandblasting
Name: Gasoline Cover
Material: Stainless Steel 316
Process: Investment Casting
Finish: Shot Blasting
Process: Investment Casting
Finish: Shot Blasting
Name: Worm Gear
Material: Stainless Steel 304
Process: Investment Casting
Finish: Vibration Polish
Process: Investment Casting
Finish: Vibration Polish
Name: Agricultural Machinery Parts
Material: Carbon Steel
Process: Precision Casting
Finish: Shot Blasting
Process: Precision Casting
Finish: Shot Blasting
Company Introduction
24 years.
Linyi Hongsheng Foundry Co., Ltd was established in 1998, with registered capital of 8 million RMB and total investment of 20 million RMB. Our company is located in Linyi, a well-known goods distribution center.
Production Capacity
In addition, we take the lead in passiing ISO9001:2000 among the same industry. In 2007, we imported spectrum analyzer from Germany and set up silicon colloidal medium-temperature precision casting production line. Our building area for the first phase is about 4,500 square meters and the initial monthly productivity is about 60-80 tons. We can make precision foundry products from stainless steel, carbon steel, alloy steel, non-ferrous steel, etc.
Production Ablity
At present, we can do various products,referring to auto parts, mechanical components, pump valve parts, building hardware, petrochemical equipment, cooker accessory, bath accessory, medical instrument accessory and sports equipment. The materials include 201, 202, 303, 304, 304L, 316, 316L, 1Cr18Ni9Ti, 430, 440,1008,1020,20NiCrMo, 42CrMo4 and non-magnetic stainless steel. The minimum weight of casting we can do is 2g, and the maximum weight is 30kg. The minimum casting space available is 0.75mm, and the thinnest is 0. 15mm. The longest blind hole (diameter 30mm) we can make is 170mm.
Customers
Our products get good reputation by our customers in America,Canada,Germany, France, England, Japan,etc.We will provide good quality products and best service for all our customers.
Production Capacity
In addition, we take the lead in passiing ISO9001:2000 among the same industry. In 2007, we imported spectrum analyzer from Germany and set up silicon colloidal medium-temperature precision casting production line. Our building area for the first phase is about 4,500 square meters and the initial monthly productivity is about 60-80 tons. We can make precision foundry products from stainless steel, carbon steel, alloy steel, non-ferrous steel, etc.
Production Ablity
At present, we can do various products,referring to auto parts, mechanical components, pump valve parts, building hardware, petrochemical equipment, cooker accessory, bath accessory, medical instrument accessory and sports equipment. The materials include 201, 202, 303, 304, 304L, 316, 316L, 1Cr18Ni9Ti, 430, 440,1008,1020,20NiCrMo, 42CrMo4 and non-magnetic stainless steel. The minimum weight of casting we can do is 2g, and the maximum weight is 30kg. The minimum casting space available is 0.75mm, and the thinnest is 0. 15mm. The longest blind hole (diameter 30mm) we can make is 170mm.
Customers
Our products get good reputation by our customers in America,Canada,Germany, France, England, Japan,etc.We will provide good quality products and best service for all our customers.
Latest News!!
New wax injection machine set up finished. Max-pressure is 35 tons,wax pattern largest size is 800*600 mm. It's the biggest wax injection machine in China. With the help of this machine,we are able to cast big steel parts for our customers by silical sol investment casting way.
More Main Proucts:
- Hongsheng holds the ISO 9001 :2008 and ISO 1 4001 :2004 certifications and therefore complies with all the essential quality control procedures and environmental respect rules which guarantee the reliability of all our manufactured products, both during the direct processes and in the auxiliary workshops.
Q1: What is our payment term?
A:T/T, Paypal.
Q2: How can we quote for you?
A: Please email us enquiry with all technical drawings you have, such as material grade, tolerance, mechanical
properties, heat treatment, requirements, etc. Our specialized engineers will check and quote for you within 24 hours.
Q3: Which product are often processed by your company ?
A: Auto parts,machinery part, marine part, Kitchen parts, Agricultural parts.
Q4: Which material are often used ?
A: Stainless steel. alloy steel, carbon steel, aluminum, copper.
Q5: Which finish you can provide ?
A:Sand blasting, Tumbling, Polishinh, Electro-polishing, Mirror Polishing, Powder coating, Electrophoresis, ETC.
Q6: What is the MOQ ?
A: Based on the product, normal 100 pcs.
Q7: Can we make the samples?
A: Is Available, 15-20days for sampling.
Q8: How about for the lead time?
A: Normally about 35 days for mass production, pls inform us if it is urgent order.
